Lei LI

Selected Publications

1. TVCG

   WSDesc: Weakly Supervised 3D Local Descriptor Learning for Point Cloud Registration

   Lei Li, Hongbo Fu, and Maks Ovsjanikov

   IEEE Transactions on Visualization and Computer Graphics 2022

   Abs PDF Code

   In this work, we present a novel method called WSDesc to learn 3D local descriptors in a weakly supervised manner for robust point cloud registration. Our work builds upon recent 3D CNN-based descriptor extractors, which leverage a voxel-based representation to parameterize local geometry of 3D points. Instead of using a predefined fixed-size local support in voxelization, we propose to learn the optimal support in a data-driven manner. To this end, we design a novel differentiable voxelization layer that can back-propagate the gradient to the support size optimization. To train the extracted descriptors, we propose a novel registration loss based on the deviation from rigidity of 3D transformations, and the loss is weakly supervised by the prior knowledge that the input point clouds have partial overlap, without requiring ground-truth alignment information. Through extensive experiments, we show that our learned descriptors yield superior performance on existing geometric registration benchmarks.

2. CVPR

   PointDSC: Robust Point Cloud Registration using Deep Spatial Consistency

   Xuyang Bai, Zixin Luo, Lei Zhou, Hongkai Chen,  Lei Li, Zeyu Hu, Hongbo Fu, and Chiew-Lan Tai

   In Proceedings of the IEEE/CVF Conference on Computer Vision and Pattern Recognition 2021

   Abs PDF Code

   Removing outlier correspondences is one of the critical steps for successful feature-based point cloud registration. Despite the increasing popularity of introducing deep learning methods in this field, spatial consistency, which is essentially established by a Euclidean transformation between point clouds, has received almost no individual attention in existing learning frameworks. In this paper, we present PointDSC, a novel deep neural network that explicitly incorporates spatial consistency for pruning outlier correspondences. First, we propose a nonlocal feature aggregation module, weighted by both feature and spatial coherence, for feature embedding of the input correspondences. Second, we formulate a differentiable spectral matching module, supervised by pairwise spatial compatibility, to estimate the inlier confidence of each correspondence from the embedded features. With modest computation cost, our method outperforms the state-of-the-art hand-crafted and learning-based outlier rejection approaches on several real-world datasets by a significant margin. We also show its wide applicability by combining PointDSC with different 3D local descriptors.

3. CVPR

   End-to-End Learning Local Multi-view Descriptors for 3D Point Clouds

   Lei Li, Siyu Zhu, Hongbo Fu, Ping Tan, and Chiew-Lan Tai

   In Proceedings of the IEEE/CVF Conference on Computer Vision and Pattern Recognition 2020

   Abs PDF Code

   In this work, we propose an end-to-end framework to learn local multi-view descriptors for 3D point clouds. To adopt a similar multi-view representation, existing studies use hand-crafted viewpoints for rendering in a preprocessing stage, which is detached from the subsequent descriptor learning stage. In our framework, we integrate the multi-view rendering into neural networks by using a differentiable renderer, which allows the viewpoints to be optimizable parameters for capturing more informative local context of interest points. To obtain discriminative descriptors, we also design a soft-view pooling module to attentively fuse convolutional features across views. Extensive experiments on existing 3D registration benchmarks show that our method outperforms existing local descriptors both quantitatively and qualitatively.

4. TVCG

   Sketch-R2CNN: An RNN-Rasterization-CNN Architecture for Vector Sketch Recognition

   Lei Li, Changqing Zou, Youyi Zheng, Qingkun Su, Hongbo Fu, and Chiew-Lan Tai

   IEEE Transactions on Visualization and Computer Graphics 2020

   Abs PDF Code

   Sketches in existing large-scale datasets like the recent QuickDraw collection are often stored in a vector format, with strokes consisting of sequentially sampled points. However, most existing sketch recognition methods rasterize vector sketches as binary images and then adopt image classification techniques. In this article, we propose a novel end-to-end single-branch network architecture RNN-Rasterization-CNN (Sketch-R2CNN for short) to fully leverage the vector format of sketches for recognition. Sketch-R2CNN takes a vector sketch as input and uses an RNN for extracting per-point features in the vector space. We then develop a neural line rasterization module to convert the vector sketch and the per-point features to multi-channel point feature maps, which are subsequently fed to a CNN for extracting convolutional features in the pixel space. Our neural line rasterization module is designed in a differentiable way for end-to-end learning. We perform experiments on existing large-scale sketch recognition datasets and show that the RNN-Rasterization design brings consistent improvement over CNN baselines and that Sketch-R2CNN substantially outperforms the state-of-the-art methods.

5. CG&A

   Fast Sketch Segmentation and Labeling with Deep Learning

   Lei Li, Hongbo Fu, and Chiew-Lan Tai

   IEEE Computer Graphics and Applications 2018

   Abs PDF Video Code Best Paper Award Runner-Up

   We present a simple and efficient method based on deep learning to automatically decompose sketched objects into semantically valid parts. We train a deep neural network to transfer existing segmentations and labelings from three-dimensional (3-D) models to freehand sketches without requiring numerous well-annotated sketches as training data. The network takes the binary image of a sketched object as input and produces a corresponding segmentation map with per-pixel labelings as output. A subsequent postprocess procedure with multilabel graph cuts further refines the segmentation and labeling result. We validate our proposed method on two sketch datasets. Experiments show that our method outperforms the state-of-the-art method in terms of segmentation and labeling accuracy and is significantly faster, enabling further integration in interactive drawing systems. We demonstrate the efficiency of our method in a sketch-based modeling application that automatically transforms input sketches into 3-D models by part assembly.
